ST-CQD-80
Our denim quilt cover is the real deal. The genuine article. Enzyme washed, double stitched, complete with brass zippers on the euros, we just know youll end up loving this bedlinen even more than your favourite pair of jeans.
Description
Overview
The textile, textile product, and apparel manufacturing industries include establishments that process fiber into fabric and fabric into clothing and other textile products. While most apparel manufacturers worldwide rely on people to cut and sew pieces of fabric together.
Details
| Item | Parameter | Unit |
|---|---|---|
| Pressure Range P | 2.8 | KN |
| Stroke S | 50-200 | mm |
| Riveting Time T | 0.1～9.9 | S |
| Stroke Frequency N | 0.1~30 | min⁻¹ |
| Max Die Height H1 | 345 | mm |
| Min Die Height H2 | 345-S | mm |
| Throat Depth A | 95 | mm |
| Working Pressure | 0.3～0.8 | Mpa |
| Operating Temperature | -30 ~ 50 | ℃ |
| Worktable Size | 240×200 | mm |
| Worktable Thickness | 30 | mm |
| Overall Dimensions | 500 × 550 × (920+S) | mm |
| Weight | 60 | kg |
| Power Supply | 220V 50Hz | |
| Input Pressure | 0.3～0.8 | Mpa |
| Packing Dimensions | 570×620×1300 | mm |
| Gross Weight | 85 | kg |
